Mini Dumper – 500 kg Hydraulic Tip
Designed for professional material handling, this 500 kg mini dumper is powered by a reliable LONCIN 270cc 9HP OHV four-stroke petrol engine, delivering dependable performance for construction, landscaping, agriculture and estate maintenance.
The 3-forward / 1-reverse mechanical transmission provides smooth and reliable operation, while mechanical lever steering ensures precise manoeuvrability in confined spaces and on uneven terrain. The hydraulic tipping system enables quick and effortless unloading, helping to improve productivity on demanding jobs. An integrated automatic braking system enhances operator safety, especially when working on gradients.
With a maximum payload of 500 kg on level ground and 275 kg on slopes, this compact dumper is ideal for transporting soil, gravel, sand, firewood and other bulk materials.
Key Features
LONCIN 270cc 9HP OHV four-stroke petrol engine
Recoil start, with electric start available as an option
3 forward + 1 reverse mechanical transmission
Maximum travel speed: 3.6 km/h forward / 1.2 km/h reverse
Mechanical lever steering
Hydraulic tipping system
Lever-operated safety system with automatic brake
Maximum payload: 500 kg
Maximum payload on slopes: 275 kg
Maximum admissible slope: 30°
Heavy-duty steel construction for professional use
| Specification / Parameter | |
| Motor | LONCIN 270CC 9HP |
| Engine Type | OHV Single Cylinder 4-Stroke Gasoline |
| Transmission | 3F + 1R (3 Forward, 1 Reverse) |
| Starting System | Recoil / Electric (Optional) |
| Type of Transmission | Mechanical |
| Working Speed (Max) | 3.6/1.2 km/h |
| Overall Dimensions (L×W×H) | 1770 × 770 × 1020 mm |
| Bucket Dimensions (L×W×H) | 1100 × 700 × 350 mm |
| Dump System | Hydraulic |
| Security System | With Lever and Automatic Brake |
| Type of Direction | Mechanical with Levers |
| Max Load (Flat / Slope) | 500 kg / 275 kg |
| Admissible Slope | 30° |
| Unloaded Weight | 280 kg |
