Mini Trencher – 7HP-MT450-3100
Designed for fast and precise trenching, this 7HP mini trencher is ideal for installing irrigation systems, drainage pipes, cables and utility lines. Powered by a reliable 212cc four-stroke OHV gasoline engine, it delivers dependable performance and excellent digging efficiency in a compact, easy-to-manoeuvre design.
Featuring a 100 mm trench width and an adjustable digging depth of up to 450 mm, the trencher is equipped with a carbide alloy digging chain, 21 heavy-duty cutting teeth and a Kevlar dual V-belt drive for maximum durability and reliable operation in demanding conditions.
Ideal for landscaping, agriculture, irrigation, construction and utility installation.
Key Features
212cc 7HP four-stroke OHV gasoline engine
Adjustable trenching depth up to 450 mm
100 mm trench width
Carbide alloy chain with 21 heavy-duty cutting teeth
Kevlar dual V-belt drive with centrifugal clutch
Chain speed up to 550 m/min
Durable 42CrMo tooth holders for extended service life
Compact and easy to transport
Ideal for irrigation, cable laying and drainage projects
| Engine | DUCAR |
| Engine Type | Single Cylinder, 4 Stroke, Air-Cooled, OHV |
| Displacement/ HP | 212 cc; 7 HP |
| Start | Recoil |
| Belt | 2 x V-Belts |
| Belts Material | Kevlar |
| Clutch | Centrifugal Clutch |
| Carbide Tip | 21 x Carbide Alloy High-Pressure Teeth |
| Scraper | 7 Pcs |
| Tip Holder Material | 42CrMo |
| Trench Width | 100 mm |
| Trench Depth | 0 – 450 mm (Adjustable) |
| Blade Number | 21 pcs |
| Blade Material | Carbide Alloy |
| Chain Length | 1600 mm |
| Chain Speed | 550 m/min |
| Weight (Net) | 155 – 170 kg |
| Dimension (L×W×H) | 1760 × 700 × 900 mm |
| Packing Method | Plywood Case |
| Gross Weight | 136 kg |
| Packing Size (L×W×H) | 1030 × 770 × 860 mm |
