Electric Mini Dumper –500EAH
Scan the QR code
Electric Mini Dumper – Hydraulic Tipping
Designed for professional material handling, this electric mini dumper delivers powerful, quiet and zero-emission performance for landscaping, agriculture and construction applications. Powered by a 1000W 48V brushless DC motor, it provides smooth operation, low maintenance and extended working time of up to 10 hours on a single charge.
With a 500 kg payload capacity and a 236 L steel bucket, the dumper is ideal for transporting soil, gravel, sand, timber and garden waste. The hydraulic power tipping system (HPU) enables fast and effortless unloading, while the electromagnetic brake, tubeless tires and multiple speed settings ensure safe and reliable operation on a wide range of job sites.
Ideal for landscaping, nurseries, farms, construction sites, parks and municipal maintenance.
Key Features
1000W 48V brushless DC motor
Load capacity up to 500 kg
236 L heavy-duty steel bucket
Hydraulic Power Unit (HPU) tipping system
Up to 8–10 hours working time
Electromagnetic braking system
Multiple forward speed modes and reverse drive
Battery capacity display
Tubeless tires for enhanced durability and traction
Quiet, zero-emission operation for indoor and outdoor use
| Specification | |
| Electric Motor | 1000W, 48V Brushless DC Motor |
| Brake System | Electromagnetic Brake |
| Battery | 48V 32Ah Lead-acid Battery |
| Display Screen | Battery Capacity |
| Lighting Lamp | 2 pcs × 30W |
| Working Time | 8 – 10 hours |
| Charging Time | 6 – 7 hours |
| Charging Current | 4.5A |
| Forward Speed (High / Mid / Low) | 0 – 5.0 / 0 – 4.2 / 0 – 3.3 km/h |
| Reverse Speed | 0 – 2.5 km/h |
| Load Capacity | 500 kg |
| Tipping System | Hydraulic Power Unit (HPU) |
| Bucket Dimensions (L×W×D) | 1185 × 670 × 400 mm |
| Bucket Volume | 236 L |
| Front Wheel | 16 × 6.5 – 8 Tubeless Tire |
| Rear Wheel | 13 × 5.00 – 6 Tubeless Tire |
